FIBARO - Double Switch Z-Wave+ FGS-223 (FIBARO Double Switch 2)

The Fibaro Z-wave Plus Double Switch 2

The Fibaro Double Switch 2 was designed to activate and deactivate electronic appliances. Thanks to its small size, it can be installed in junction boxes or flush boxes. The module is controlled either by the Z-Wave network or a simple switch. The power and energy measurement function enables you to monitor and reduce your electricity bills. Connect your FIBARO Double Switch 2 to your Z-Wave system and other devices to benefit from almost endless possibilities!

Practical connector blocks - easy installation

The Double Switch 2 is equipped with thicker connector blocks in order to connect wires with a bigger diameter and simplify the installation process.

User-friendly configuration menu

The integrated RGB diode is a great help during the installation process. The light will show if the Double Switch 2 has been added or removed from the network. You can also see whether a calibration or an update has been successful.

Z-Wave network coverage tester

Use the Fibaro Double Switch 2 to check the quality of the signal in the Z-Wave network. The integrated RGB diode will help you to verify whether the location you have selected for installation is suitable.

 A stronger signal

The Fibaro Double Switch 2 has an extended signal range, which offers you more installation possibilities and broader network coverage.

Software updates

You can update the software of your Fibaro Double Switch 2 to the latest version when it becomes available. This way, you have access to the latest functionalities, without the need to replace your module.

Easy to install

Simply place the module in the flush box and connect it to an existing system. The small size of the module enables you to place it in many practical locations.

Scene management

Even the most complex actions can be activated using a wall switch connected to a module. With a simple touch of a button when entering a room, it is just as natural as turning on the lights. 1 to 3 presses and a long press can be assigned to four different actions

Intelligent notifications

The Fibaro Double Switch 2 integrates numerous security measures, which protect it from voltage drops, overheating or overloading. If one of these events occurs, the system will immediately send you a notification.

Notification of unused appliances

The Fibaro Double Switch 2 enables you to monitor the electrical appliances which are currently inactive. The system informs you if you leave a appliance on and allows you to turn it off remotely.

Automatic power break upon contact with water

A flood sensor, in conjunction with a solenoid valve and the Double Switch 2 will protect your home from floods, offering the highest possible level of effectiveness.

Use limits and appliance monitoring

This function enables you to define the upper and lower energy consumption limits. Once the limit is reached, the module can inform you or automatically deactivate the appliance.

Power and energy measurement

The new Double Switch 2 enables you to measure the power and energy of the connected load. You can see how much energy is used in your home thanks to clear graphs and use this information to reduce your electricity bills.

Your mobile device is your remote control

You can control the modules and receive information through your personal computers and mobile devices. The Double Switch 2 does not require expensive control panels in order to function.

Take care of your children

Are you a parent or do you plan to become one in the near future? Monitoring your children's homework and play time, as well as the capacity to automatically activate their favourite multimedia devices may interest you.

Help to protect

Surround your children with the best care. The Double Switch 2 allows you to cut the power supply to domestic appliance when they are not in use.

Your home is wherever you are

Like the entire FIBARO system, the Double Switch 2 module may be controlled from anywhere on earth. All you need is an internet connection

.

To summarise

The Z-Wave series 500 chip and the Z-Wave Plus protocol offer more capacities, which were not available before. The power and energy measurement function enables you to optimise your electricity bills. By using the scene activation mechanism, you can adapt your home to your preferences.

Warning:

• This module requires a neutral pin
• The output is not free from charge. It therefore does not enable a dry contact or a load to be control with any power voltage other than the input.

Functionalities

• Remote control two lamps/appliances
• Can be installed behind an existing switch
• On/Off function
• Integrates the Z-Wave series 500 chip
• Communication 250% faster compared with standard Z-Wave devices
• Integrated scene activation mechanism
• Security and notification categories of communication
• Configuration menu with a diode
• Measurement of the energy and power of the connected appliances
• Support secure mode (Z-Wave network security), encrypted with AES-128 encryption
• Z-Wave network coverage tester
• OTA software update (depending on the controller)
• Larger connector blocks to facilitate wiring
• Rounded shape to meet the strictest standards
• Toggle switch use
• Use instead of a stepping switch
• Small, discreet and pretty
• Ease of use and installation

Technical Specifications

• Type of module: Z-Wave receiver
• Power: 100 - 240V~, 50/60Hz
• Wiring 3 wires, neutral to get requirements
• Max. power: 8A (resistive load only)
• Frequency: 868.42 MHz
• Transmission distance:: 50m outdoors, 40m indoors
• Signal power: 1mW
• Dimensions: 42.5mm X 38.25mm X 20.3mm (L X W X H)
• Operating temperature: 0-35°C
• Standards :
  • EMC 2014/30/EU
  • RED 2014/53/EU
  • RoHS 2011/65/EU
  • LVD 2014/35/EU
