Introduction
The TZ56S dimmer switch allows the user to transfer a connected charge, whether manually as with a classic dimmer switch, or remotely using the wireless Z-Wave Plus protocol.
It can be included in a Z-Wave network and managed by a Z-Wave remote control. The dimmer switch can control any type of charge, whether a lighting source or an electrical appliance.
The TZ56S dimmer switch supports association commands (group 1). It is possible to associate up to 5 other peripheral devices in order to control them manually using the dimmer switch.
Attention: We recommended choosing a flush mounted box of at least 66mm in diameter and 50 mm in depth.
Functionalities
- Controls a lamp or an appliance remotely
- Can be installed in place of an existing dimmer switch
- ON/OFF function
- Supports association commands (group 1)
- Controls the locally connected charge
- LED status indicator
Technical Characteristics
- Module type: Z-Wave Plus receiver
- Colour: white
- Supply: 230V, 50 Hz
- Frequency: 868.42 MHz
- Cabling: 3 wires, neutral necessary
- Maximum power: 6A (1380W)
- Transmission range: 30m indoors
- Display: blue LED
- Dimensions: 86 x 86 x 47 mm
Specifications
| Protocol | Z-Wave Serie 500 |
|---|---|
| Type | Module Switch |
| Function | Actuator |
| Gateway compatibility | Fibaro Home Center - total compatibility Homey - total compatibility eedomus+ - total compatibility |
| Use | Fixture Control Lighting Control Switches and Remote Control |
