Sunricher - Zigbee 3.0 transmitter module
New
CHF54.00
Tax included
Sunricher's Zigbee 3.0 transmitter module connects up to 4 pushbuttons for scene control.
In stock. Ordered before 5pm, delivered the next working day
This module has a 100-240VAC power input to supply its integrated transmitter. This transmitter sends wireless radio signals that are used to remotely control compatible devices.
It allows learning and controlling Zigbee lighting devices that support the Green Power function and controlling 4 scenes for lighting devices paired with 4 push buttons.
FUNCTIONS
- Communicates with Zigbee lighting receivers that support the Green Power function
- 4-channel push-button interface for simple installation in a wall box
- With 100-240VAC power input to supply the integrated transmitter
- Compatible with Zigbee Green Power and existing switches, regardless of the manufacturer
- Sends wireless radio signals that are used to remotely control compatible devices
- Allows learning and controlling Zigbee lighting devices that support the Green Power function and controlling 4 scenes for lighting devices paired with 4 push buttons
TECHNICAL SPECIFICATIONS
- Switch type: Scene
- Transmission range: 10-30 m (typical)
- Radio frequency: 2.4 GHz
- Power supply: 100-240 VAC, 50/60 Hz
- Power consumption: less than 0.5 W
- Number of push buttons: 4
- Connector type: Plug-in
- Wire size: 0.2 - 1.5 mm2 (AWG28 - AWG14)
- Dimensions: 49.8 x 43 x 15.1 mm
- Operating temperature: -20 ℃ ~ +45 ℃
- Operating humidity: 10 % ~ 95 % RH non-condensing
- IP protection: IP20
Specifications
| Use | Fixture Control Lighting Control Switches and Remote Control |
|---|---|
| Type | Module |
| Function | Actuator |
| Protocol | Zigbee |
-
