SONOFF SWV-BSP - Zigbee 3.0 Smart Water Valve
New
CHF28.90
Tax included
Ultra-compact Zigbee 3.0 intelligent module to transform your roller shutters into a connected system. Control opening by percentage from your smartphone, program automatic schedules and create home automation scenes. Installs discreetly in your existing wall box, compatible with your existing switches. Automatic stroke calibration and built-in Zigbee repeater function. The simple, economical way to modernize your shutters.
Introduction
The SONOFF MINI-ZBRBS is a compact Zigbee 3.0 module that turns any motorized roller shutter into an intelligent system. Ultra-compact (39.5×33×16.8 mm), it installs in standard wall-mounted boxes and supports motors up to 1A. Compatible with Zigbee gateways, it offers remote control, time programming and integration into home automation scenes. Its Zigbee repeater function enhances network coverage.
Key features
Ultra-compact design
- Dimensions: 39.5×33×16.8 mm, weight 25.1g
- Fits into standard wall-mounted boxes
- White polycarbonate housing
- Invisible installation behind cover plate
Motor compatibility
- Power supply: 100-240V~ 50/60Hz, max load 1A
- Compatible with tubular motors for roller shutters, awnings and electric curtains
- 2 outputs (Lout1/Lout2) for bidirectional control
- Protection: automatic shutdown after 2 minutes
- Direction reversal possible
Zigbee 3.0 technology
- Microcontroller EFR32MG21
- Frequency 2405-2480 MHz, power ≤10dBm
- Integrated repeater function for network extension
Percentage control
- Precise positioning from 0% to 100
- Automatic or manual stroke calibration
- High and low position memory
- Recalibration possible in case of drift
Switch compatibility
- Momentary switches (push-buttons)
- 3-position toggle switches
- 3 modes: Edge Mode (default), Pulse Mode, Following Mode
- Mode change by triple-clicking on module button
Button and LED indicator
- Multifunction button for configuration
- Blue LED: steady on (connected), slow flashing (pairing), fast flashing (fault), breathing (calibration)
EWeLink application
- Remote control iOS/Android
- Opening/closing and positioning by percentage
- Time programming
- Multi-device intelligent scenes
- Family access sharing
Technical specifications
General
- Model : MINI-ZBRBS (MINI Extreme series)
- MCU: EFR32MG21
- Dimensions: 39.5×33×16.8 mm
- Weight: 25.1g
- Material: white PC
Electrical
- Power supply: 100-240V~ 50/60Hz
- Load: 1A max
- Pulse voltage: 4kV
- Cycles: 10,000
Environment
- Use: Indoors only
- Operating temperature : -10°C to +40°C
- Humidity: 5-95% RH non-condensing
- Max. altitude: 2000m
Connectivity
- Protocol: Zigbee 3.0 (2405-2480 MHz)
- Power: ≤10dBm
- Zigbee repeater: Yes
Wiring
- 6 terminals: N (neutral), L (phase), Lout1/Lout2 (motor outputs), S1/S2 (switches)
- Recommended diameter: 18AWG to 14AWG copper
Certifications
- CE, FCC (2APN5-MINIZBRBS), RoHS
- EU Directive 2014/53/EU
